- Technical Specifications
- Type: Front-firing active driver, down-firing passive
- Active Driver Size & Material: 12 in. (305mm) long-throw, CarbonAlloy™ cone structure, die cast alloy chassis
- Passive Radiator Size & Material: 12 in. (305mm), Carbon/Carbon flat cone structure, steel chassis
- Low Frequency Extension: -6 dB at 19Hz
- Input Connectors: High Level Neutrik Speakon, Low Level (2) RCA, (1) LFE RCA, (1) LFE XLR
- Output Connectors: High Level Neutrik Speakon, (1) Low Level RCA, (1) LFE RCA or (1) LFE XLR
- Power Output: 850 watts (RMS)
- Amplifier Type: Linear Class D
- Wireless Capability: REL AirShip Direct (sold separately)
- Dual Parametric Filter: N/A
- Finish: Piano Black Lacquer, Gloss White Lacquer 8 coats
- Protection System
- Fully Electronic Set Safe: Yes
- D.C. Fault: Yes
- Output Short: Yes
- Mains Input Voltage: 220-240 volts, 110-120 volts for certain markets
- Fuses: 8 Amp semi delay 220 volts operation, 15 Amp semi delay 120 volts operation
- Supplied Accessories
- Mains Lead: Yes
- Neutrik Speakon: Yes (10 Meters Nominal)
- Interconnect: –
- User Manual: Yes
