Cabletronix CT-HDVD-HDWR-RX HDMI Wireless Receiver

Cabletronix CT-HDVD-HDWR-RX HDMI Wireless Receiver

The CT-HDVD-HDWR-KIT is a long range wireless HDbitT HDMI AV transmitter that canextend high definition audio and video to any HDTV display up to 400’ away withline of sight or 150’ through normal buildings. It supports HD resolutions upto 1080p and provides remote transmission of infrared control from themonitoring device to the source device. The CT-HDVD-HDWR-KIT is the perfectsolution for distributing high definition video and audio in locations wherewires can not be run. Up to three total receive units can be used with a singletransmission unit.

Key Features

• Transmits anHDMI signal from source device to a display device up to 400’ with line ofsight or 150’ through normal buildings
• Full HD1080p transmission
• Compliantwith HDMI and HDCP
• Supports IRremote control function to source device
• No cablingis required between transmitter and receiver
• Low profiledesign with an simple and clean installation

TechnicalSpecifications

HDMI signal
HDCPcompatible
Transport protocol
HDbitT
Supported resolutions
480i@60Hz,480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
IR remote control
Supports 20- 60kHz IR remote device
Transmission frequency
5.8 GHz
Transmission distance
400’ at1080p 60Hz with line of sight / 150’ at 1080p 60Hz through a normal building
Working temperature
0C – 60C
Power supply
DC5V/2A
Transmitter power consumption
<8.5W
Receiver power consumption
<5.5 W
Housing material
Metal
Transmitter dimensions
7.70” (W) x5.42” (D) x 1.22” (H)
Receiver dimensions
7.70” (W) x5.42” (D) x 1.22” (H)
Transmitter weight
1.17 lbs.
Receiver weight
1.16 lbs.
Color
Black
Item Includes
1x – HDMITransmitter
1x – HDMIReceiver
