Mixer
- 24 Mic/Line Inputs
- 2 Dual Stereo Inputs
- DuoPre Preamp with 69 dB Gain range
- 6 AUX Sends
- USB Send and Return
- 4-Band EQ with 2 x semi parametric midrange
- Insert per channel
- 4 Sub groups
- High Pass Filter
- Mute per channel
- Stereo Return
- 2-Track Return
- 6.3 mm Headphone connector
- Stereo Record Output
- Alternative Stereo Output
- Mono sum of LR output
- 2 Matrix Outputs
- Master LR
- 12-Segment L/R meters
- Master control for all AUX sends
- Weight: 21 kg
- Dimensions: 930 x 560 x 129 mm
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceNovember 2007
- Item number150866
- Sales Unit1 piece(s)
- Simultaneous channels 26
- Mic-In 24
- Mono Line-in 24
- Stereo-In 4
- Hi-Z Input 0
- Phantom Power 48 V
- Master Out XLR
- Aux Ways 6
- max. Pre Aux Channels 4
- PC Interface USB-B
- Audio Interface Input 2
- Audio Interface Output 2
- Multitrack-Recording No
- USB/SD Direct Record No
- Rec Out (Analog) Yes
- Low Cut Yes
- Inserts Yes
- Direct Out Yes
- Parametric Yes
- Compressor No
- Panorama Yes
- PFL Yes
- FX Processor 0
- USB Playback No
- Bluetooth Playback No
- Lamp connection No
- Footswitch No
- Matrixmixer No
- Bag No
- Zones 0
- 19″ Rackmount No
- Width1135 mm
- Depth560 mm
- Height129 mm
- Weight18 kg
- Parallel usable Channels26
- Mic Ins24
- Mono Line Ins24
- Stereo Ins4
- Number of Pre Aux max.4
- InsertYes
- Effect Processor0
- USB PlayNo
- Bluetooth PlayNo
- Lamp ConnectorNo
- Foot SwitchNo
- RackmountNo
